The MADAS Automatic Electric Gas Solenoid Valve is the intelligent link between gas leak detection and disaster prevention. Upon receiving a danger signal from the control panel, this professional Italian valve immediately halts gas flow without human intervention, giving your gas network true intelligence in safety management.
MADAS Electric Gas Valve — Automatic Response to Prevent Disasters
In the event of a gas leak, seconds make the difference. The MADAS electric valve responds instantaneously to the shut-off signal from the gas detector or control panel, cutting off gas flow before concentrations reach hazardous levels.
MADAS Automatic Electric Gas Valve — Technical Specifications
Category: Automatic Shut-Off Valve
Brand:MADAS
Origin : Italy
Size : 1 Inch
Operation Type: Normally Open (N.O.)
Voltage :230V / 50-60 Hz
Max Operating Pressure :6 Bar
Protection Rating :IP65
Weight :1 kg
Item Code :GASE-0039
Operational Information
- Normally Open (N.O.): The valve remains open under normal conditions and closes when power is cut or an emergency signal is sent.
- Operates on 230V AC—perfectly compatible with the Saudi electrical grid.
- Withstands an operating pressure of up to 6 Bar, making it suitable for a wide range of applications.
Key Features of the MADAS 1-Inch Electric Gas Valve
Instant Emergency Shut-Off
Immediate response to closing commands from the gas detector or control panel without the need for manual intervention.
N.O. Design for Power-Loss Safety
In the event of a power failure, the valve can be configured to close, preventing potential leaks during absences.
IP65 Protection for Harsh Environments
Engineered to withstand moisture and dust in commercial kitchens and industrial zones without compromising efficiency.
6 Bar Operating Pressure
Covers a broad spectrum of residential, commercial, and industrial gas network pressures in a single application.
Certified MADAS Italian Craftsmanship
MADAS is a specialized Italian brand in gas valves, globally certified by leading safety organizations.
Why Choose the MADAS 1-Inch Automatic Gas Valve?
- ✅ Instant shut-off without human intervention.
- ✅ Integrates with all gas detection and alarm systems.
- ✅ Compatible with Saudi voltage standards (230V).
- ✅ IP65 protection for humid and dusty environments.
- ✅ Certified Italian brand with international specifications.
Common Applications
Large Restaurants and Hotels
Installed alongside gas detectors to automatically close the supply if a leak is detected in commercial kitchens.
Large Residential Buildings
Secures main gas inlets for towers and residential complexes with centralized control capabilities.
Hospitals and Vital Facilities
Ensures immediate gas cutoff in facilities where emergency response delays cannot be tolerated.
High-Consumption Factories
Controls gas flow within industrial production lines with the ability to integrate into SCADA systems.
Installation and Maintenance
Installation Steps
- Shut off the gas from the main source and ensure full ventilation.
- Determine the installation site on the main gas line after the regulator.
- Install the valve into the pipeline, noting the specified flow direction.
- Connect the 230V electrical wiring from the control panel.
- Link the signal wires from the gas detector or alarm panel.
- Test the entire system before actual operation.
Performance Maintenance Tips
- 🔧 Periodically inspect the valve to ensure seal integrity.
- 🔧 Clean the exterior body regularly to prevent residue buildup.
- 🔧 Test the open/close cycle monthly to verify response time.
- 🔧 Check electrical connections every six months.
Important Notes Before Purchase
- Ensure the 1-inch size matches your gas pipeline.
- Requires a 230V electrical connection.
- Installation must be performed by a licensed electrician and gas specialist.
- Must comply with Saudi Civil Defense safety requirements.
Why Buy from Al-Watani Al-Muhaidib?
- Expertise in supplying professional gas equipment.
- Fast delivery across all regions of Saudi Arabia.
- Specialized technical support to help you choose the right size and type.
- Official invoices for facilities and corporations.
Frequently Asked Questions (FAQ)
What is the difference between N.O. and N.C. in gas valves?
N.O. (Normally Open) means the valve stays open during normal operation and closes during an emergency. N.C. (Normally Closed) is the opposite. For gas safety, N.O. is typically used so it can shut off automatically during power outages or alarms.
Does it work with Natural Gas?
It is primarily designed for LPG networks. We recommend consulting a specialist to determine compatibility with Natural Gas systems.
Is it loud during operation?
It produces a slight "click" sound during opening and closing, which is normal for electromagnetic solenoid valves.
